Orthopaedics

We offer a comprehensive range of orthopaedic treatment for cats and dogs in the Maidenhead area

Orthopaedics at Hall Place Veterinary Centre

At Hall Place Veterinary Centre we offer the very latest in expertise and equipment to deal with all bone, joint or muscle diseases, from simple lameness cases through to complex fractures.

Because of this expertise we run a busy referral service dealing with the more complicated and serious orthopaedic cases from other veterinary practices, both local and not so local.

  • If you are a client from another practice please contact your own practice to arrange a referral.
  • If you are a referring veterinary surgeon please telephone 01628 622086 to discuss a case or arrange a referral. Please note, we offer a free verbal radiography reporting service (usually same day) and free advice on management of your cases.



We offer a comprehensive range of orthopaedic treatment for cats and dogs from lameness investigation, joint surgery through to complex fracture management.

  • Cruciate Injury and TPLO Surgery
  • Patella Luxation
  • Fracture Repair
  • Investigation of Lameness
  • Investigation of Joint Disease
  • Arthroscopy
  • Medical Management of Lameness
  • Joint Surgery
  • Referring Vets

Cruciate Injury and TPLO Surgery

Cruciate Injury

Cruciate Ligament Injury is the term used to describe any sprain, partial tear or more commonly, complete rupture (where the ligament is completely torn) of the Cruciate Ligament, inside the dog (or cat) knee.

Cruciate Ligament Injury is an important cause of lameness in the dog, and can lead to permanent severe lameness, and/or debilitating arthritis, if not managed or treated correctly.

What is the Cruciate Ligament, and why is it so important?

The knee joint (or stifle as it is known in animals) is principally a hinge joint between the femur (thigh bone) and the tibia (shin bone). The knee joint is held together by a number of strong ligaments, including the collaterals and the cruciates (see diagram).





The Medial and lateral collateral ligaments prevent the knee from hinging from side to side, and the cruciate ligaments prevent the tibia sliding backward and forward with respect to the femur.

In the diagram below, a radiograph (x-ray) shows the femur and tibia in their normal positions with the cranial Cruciate Ligament shown in red.



The outline drawings below shows that the main function of the cranial cruciate ligament is to prevent the tibia sliding in the direction of the green arrow.







If the ligament is broken the tibia slides forward when the animal bears weight. This sliding movement causes pain and inflammation in the joint. The pain will obviously cause lameness, and persistent inflammation can be associated with progression of arthritis in the joint, which can lead to permanent disability.

Typical signs of lameness associated with Cruciate Injury

Lameness associated with cruciate injury can be sudden in onset (for instance if your dog tears the cruciate at exercise), but can also be slower in onset if gradual deterioration and breakdown of the ligament occurs.

In fact what commonly happens is a mixture of both of the above, whereby you observe a gradual onset intermittent low-grade lameness, followed by a sudden onset of more severe lameness when the ligament breaks.

Typically during the early low-level lameness your dog will only be stiff when getting out of bed, or after lying down. Lameness eases up during exercise and very often lameness is forgotten altogether if the dog is distracted (i.e. chasing a squirrel). The stiffness after rest will often be worse following a period of increased exercise.

In long standing cases of cruciate injury you may notice loss of thigh muscle in the affected limb. Animals with cruciate injury will often “unweight” the injured leg, by standing with more weight on the good leg. You may notice the sore leg positioned slightly to the side of the body, with the paw not placed fully on the ground.

It is important to realise that these are typical signs associated with cruciate injury. Individual cases may present quite differently, and other causes of hind-limb lameness (i.e. hip injury or hip arthritis) can present in a very similar manner.

How do we treat Cruciate Injury?

How we choose to treat cruciate injury will depend on several factors including:

  • The degree of damage to the ligament
  • The size and weight of your dog
  • The type of lifestyle/activity etc.

Low-grade Injury i.e. simple sprain

In the same way we might treat a sprained ankle in ourselves, simple ligament sprain can often be treated by a short period of rest and the use of anti inflammatories.

Rest can vary between total restriction of all activity (i.e. cage confinement and lead walking only in the garden for toilet purposes), or can simply mean moderation of exercise (i.e. “house arrest” and only 10-15 minutes lead walking once or twice per day).

If lameness resolves then gradual return to exercise is advised. Gradual build-up of exercise is extremely important. Too rapid a return to too much exercise can result in recurrence or even worsening of ligament injury.

Severe Injury/Complete Ligament Rupture

Treatment of more significant cruciate injury can be confusing. There are a large number of different surgical techniques, management options, and even more varied opinions as to how these should be implemented.

Broadly…..

  • Smaller <15kg less active dogs (and some less active larger older dogs) can possibly be managed successfully without surgery.
  • Heavier >15kg, more athletic, dogs usually require surgery.

There are breed exceptions, with certain small breeds often requiring a surgical solution (see later).

Smaller dogs (less than 15kg body weight)

A large number of dogs (and cats) less than 15kg body weight can be managed conservatively. This means surgery should not be required. In these animals fibrosis and scarring of the damaged joint, and recruitment of thigh muscles, is sufficient to stabilise the knee, and prevent the sliding movement described above.

Conservative management will often require several weeks of very strict rest and may take 2-3 months to achieve near normal function. This can appear very frustrating as recovery often appears to be slow.

A small number of dogs weighing less than 15kg will not respond to conservative management, and will go on to require surgery.

Advantages of conservative management:

  • Low cost
  • Avoids any risk of surgery
  • Often successful in small dogs and cats

Disadvantages of conservative management:

  • Recovery may be slow
  • Final recovery to normal or near normal function may not ever be quite achieved
  • No opportunity to examine joint surgically to assess other injuries (ie cartilage tear)

NB. It must be borne in mind that whilst surgery may appear to be a quicker solution, in reality the strict post-surgical rest period and recovery/physiotherapy schedule can be as long as conservative management.

Larger Dogs (more than 15kg body weight)

It is generally accepted that the majority of dogs weighing more than 15kg will require some sort of surgical treatment. Older less active dogs may still be able to be managed conservatively but recovery is usually prolonged (see above)

Advantages of surgical management:

  • Faster Recovery
  • Facilitates surgical examination of joint to assess other injuries (ie cartilage tear)
  • Final recovery usually nearer to normal function
  • Higher overall success rate

Disadvantages of surgical management:

  • Cost
  • Involves a surgical procedure

Surgical Correction of Cruciate Injury

There are a large number surgical treatments that have been tried historically, and many are still used. The majority opinion now favours two broad disciplines of surgical repair:

1. Altering the geometry of the weight bearing angle of the top of the tibia, so the tibia doesn't tend to slide forward during weight bearing.

2. Stabilising the knee using an artificial replacement ligament, either inside the knee, or alongside the knee, mimicking the action of the original cruciate ligament.

Tibial Plateau Levelling Osteotomy TPLO (including Slocum or Radial TPLO and Closing Wedge Osteotomy CWO)

In these techniques the inside of the joint is first examined to confirm that the cruciate ligament is broken. Next the condition of the cartilages (sometimes called menisci) within the knee is carefully assessed. If the menisci are damaged then surgical removal of the damaged portions is performed.

All the TPLO techniques work by altering the standing angle of the knee join by cutting and altering the angle of the top of the tibia (shin bone) immediately below the knee joint itself. The top of the tibia in the dog, tends to slope backwards, which means the tibia will slide forward when the animal bears weight (see diagram below). The intact cruciate prevents this sliding motion, as described above.



In its simplest form TPLO is performed as a 'Closing Wedge' where a triangular wedge of bone is removed from just below the joint surface. Collapsing the wedge, reduces the backward slop of the top of the tibia so that weight bearing no longer causes the tibia to slide forward.

When the wedge is closed, the bone is held in place with a plate as shown in the radiograph.





A more elegant version of the TPLO, and arguably the gold standard with respect to cruciate surgery, it involves a curved cut in the tibia so that the top of the tibia can be rotated to reduce the joint angle. This is the 'Slocum' or 'Radial Cut' TPLO. This is our preferred technique at Hall Place Veterinary Centre.

The specific type of TPLO will depend on a number of factors including the size and weight of your dog.

Other techniques include a different type of bone cut which allows the front of the tibia to be pushed forward. These include the Tibial Tuberosity Advancement (TTA) and Modified Machet Procedure (MMP).

Lateral Fabellar Extracapsular Suture

In this technique the inside of the joint is examined to confirm that the cruciate ligament is broken and to check the condition of the cartilages (sometimes called menisci) within the knee. If the menisci are damaged they may be repaired or the damaged portions removed.

An artificial replacement ligament (usually made of monofilament nylon or other braided synthetic material) is placed in a position that mimics the action of the original cruciate ligament (see diagram).



It is important to realise that this technique does not actually repair the broken cruciate ligament, nor does the replacement ligament last forever. Rather, it works by replacing the function of the cruciate ligament long enough for the animal to learn to stabilise its own knee, by a combination of fibrosis and scarring of the joint, and by the correct use of its thigh muscles. In practice, this technique is not considered as successful as the TPLO techniques.

Terriers and West Highland Terriers

A number of the terrier breeds, including the Jack Russell and, in particular, the West Highland White Terriers have an extremely marked backward slop to the tibial plateau. This predisposes them to cruciate injury and is probably, at least partly responsible, for a poor response to conservative management in these breeds. For this reason, we very often recommend a TPLO procedure in these animals despite their small size.


Rehabilitation following Cruciate Injury

Rehabilitation following cruciate injury and/or following surgical repair involves a carefully controlled program of restricted activity followed by gradually increased exercise, physiotherapy, and can include other physiotherapy type activities including hydrotherapy.

Each animal is unique and, in practice, each animal requires a bespoke rehabilitation program. We give specific advice based on your dog’s requirements. The following is a broad outline of routine advice following surgical stabilisation of cruciate injury in the dog.

Immediate post-operative period (Day 0 - 3 weeks)

The majority of animals will be non-weight bearing for the first 24-36hrs following surgery, but will gradually start to place the foot more and more each day. The aim of the first 3 week post-operative period is to restrict exercise to allow repair of the damage and inflammation caused by the ligament injury, and to allow repair of the surgery.

Strict Rest

Strict rest means almost as little activity as possible, with lead walking only in the garden, or wherever appropriate, for toilet purposes only. It is important to maintain lead control even in the garden because animals can become distracted (eg squirrels, birds etc) and attempt to run on an operated leg long before it is strong enough to withstand this. In a worse case this can cause catastrophic damage.

Toward the end of the three week period, provided walking is improving gradually, more activity can be allowed.

Ice Compresses

Ice and cooling are probably beneficial, at least in the immediate post-operative period, and are certainly known to be of great value in human patients following surgery. Provided your pet will tolerate application, ice or frozen peas can be used to gently cool the tissues around the joint. Ice etc should never be applied direct to the skin, but rather behind a cloth or towel. Repeated application of short duration is usually better tolerated and application should never exceed 10mins.

3-6 weeks

The majority of animal will be weight bearing well at 3 weeks post-op, but still obviously lame. We advise the following three exercises during the next 3 weeks:

A 5 minute walk, twice daily, increased by 1 minute each day.

This is lead walking only, and must be done at a speed slow enough that your dog walks as near to normally (ie without limping) as possible.  At the start of this period your dog will probably be able to move much faster if allowed to limp along, but it is important to re-“teach” your dog to walk properly.

Provided your dog is not lame at the end of the 5minute walk AND provided your dog is not unduly stiff that evening OR the following day, then the walk can be increased by a minute each day. If you dog does become more lame, or stiff, then walk will have to remain at current level or even be reduced. Provided all goes well, each walk should be 20-25minutes long by the end of the 3 week period.

Sit Stand Exercises

A large number of dogs do not sit properly even under normal circumstances, and will often “slouch” with one or both hind limbs turned under or away from the body.  Following knee surgery your dog will usually try to sit with the operated leg straight and angled away from the body. It is difficult to get dogs to go to the gym and do leg squats!, but we can attempt to teach them to sit properly so that the stifles (knees) are properly flexed and square to the dog. This not only flexes the knee correctly but it means the dog will use the leg when getting up, rather than solely using the other hind limb.

Not all dogs can be trained to sit properly, particularly if they have never done it, and it usually takes several days or more to make progress.  You may need to use a new command such as “neat sit” or train your dog to sit between your feet, and gradually make the gap smaller.

Passive Motion

Following surgery the range of motion of the joint (the degree to which the joint can comfortably be flexed and extended) will often be reduced. Unwillingness to flex or extend the joint can be a source of continued lameness. The range of motion of the joint can be increased by gently cycling the joint through its normal range. This also stimulates the thigh muscles. This can be done with your dog lying down or standing. 10-12 cycles twice daily is usually sufficient.

6-10 weeks

The majority of animals will be walking and trotting very well by this stage, but often still uneven in gait at a faster trot. They usually have significantly reduced leg muscle following prolonged lameness and lack of use of the limb following surgery. The aim of the next four weeks exercise, is to re-build fitness and regain lost muscle.

Gradually Increased Exercise

This initially starts as continuing the twice daily walks but increasing the pace of parts of the walk. Initially this may simply take the form of using a flexi lead so that your dog can run a short distance past you BUT, you are still in control. Running or jogging yourself can be useful, or even using a bike, provided your dog is sensible. Early in this stage, the periods of faster pace should be short but should be increased in both intensity and duration as progress is made. One size does not fit all and it is important for you to work out how best to gradually increase the tempo of your individual dogs exercise.

10 weeks+

The majority of animals will be trotting almost normally by this stage and will have recovered a significant amount of lost muscle. The aim of the next stage is transition/return to “normal” exercise.

There are a large number of variables at this point including the progress made over the previous weeks, the demeanour of the dog, and what “normal” exercise actually means. This means that a “sensible” dog that has made very good progress, and didn’t used to do a lot of exercise anyway, is almost completely recovered, and can be returned to normal activity quite quickly. On the other hand a less controlled dog, that has not made such a good recovery, but is used to uninhibited exercise in difficult terrain will have to be much more carefully managed.

The challenge is to transition from the controlled faster paced activity of the previous weeks, to off lead exercise, without your dog damaging the joint by excessive activity. What we are trying to achieve is increasingly faster and harder exercise, but still all under controlled conditions. The analogy is a footballer returning from injury who will rehabilitate by running faster and harder on a treadmill or a smooth road surface, but who will not play football itself for a long time. The key concept is (as above) that one size does not fit all, and the placid Labrador who trots round and smells the flowers can be let off lead well before the lunatic, who will complete 5 circuits of the park within 30seconds of release. You know your dog and you have to devise a plan to achieve the required transition.



Patella Luxation

Patella Luxation (Dislocating Kneecap)

Patella luxation is the term used to describe the condition in dogs and cats where the patella (kneecap), instead of sitting on the front of the knee, intermittently or permanently slips sideways to lie either side of the knee joint.

This dislocation can cause a lameness of differing severity, from the mild and inconsequential, through to permanent severe lameness. It can lead to debilitating arthritis if not managed or treated correctly.

What is the Patella and why is it so important?

The knee joint (or stifle as it is known in animals) is principally a hinge joint between the femur (thigh bone) and the tibia (shin bone). When a dog or cat walks/trots/gallops or even when just standing, the knee is prevented from collapsing by the force of the thigh muscles (quadriceps), pulling on the patella which in turn pulls on the patella ligament.





The patella normally sits in a relatively deep groove (the Trochlea) on the front of the Femur.



But in patella luxation the patella dislocates out of this groove.



Why does this happen?

In the majority of dogs the femur and tibia are relatively straight, with the quadriceps muscle, patella and patella ligament all in a straight line. This means the patella tends to sit in the correct position on the front of the knee.



However, in a significant number of the smaller breeds, especially toy breeds, the femur is not straight.

  • In affected individuals the femur is often bowed (usually towards the midline) such that the straight line through the muscle, patella and patella ligament no longer lies over the trochlea groove of the femur.
  • In these cases the patella will often dislocate out of the groove.
  • Very often the groove itself is relatively shallow increasing the tendency to luxate.
  • Depending on severity, the patella may dislocate only infrequently, or can be permanently out of place.



Typical signs of lameness associated with Patella luxation

Lameness associated with patella luxation can vary from almost no signs at all through intermittent hopping, to permanent debilitating lameness.

The most common form of lameness is intermittent hopping, often at exercise, where for the most part the animal is moving normally but at varying frequency picks up a hind limb and misses one or several steps.  The limb can occasionally become locked straight and may take several minutes to unlock.

In more severe cases lameness can be more permanent with stiffness when getting out of bed, or after lying down. The stiffness after rest will often be worse following a period of increased exercise.

It is important to realise that these are typical signs associated with patella luxation. Individual cases may present quite differently, and other causes of hind-limb lameness (i.e. hip injury or hip arthritis and particularly cruciate injury) can present in a very similar manner.

How do we treat Patella luxation?

How we choose to treat patella luxation will depend on several factors including the severity and frequency of lameness, and whether or not the patella dislocation is causing damage to the joint.

A very large number of dogs with patella luxation show no clinical signs (ie no symptoms of lameness) and therefore probably require no treatment.  This is important because it means a diagnosis of patella dislocation does not automatically mean surgery is required.

Contrary to this, there is a debate as to whether more patella luxation cases should be treated surgically to prevent future arthritis.  This argument may have some merit, but on the basis that no surgery is without risk, the relative risks should really be assessed on a case by case basis.

In addition, patella dislocation can co-exist with other causes of lameness (ie cruciate ligament injury), and it is important to correctly diagnose what is most important.

Surgical treatment of patella luxation

The majority of patella luxation cases can be corrected by a surgery which combines procedures to realign the straight axis of the muscle and patella over the trochlea groove, deepening of the grove itself, and techniques to adjust the side to side tension on the patella.

These are:

  1. Moving the point of attachment of the patellar ligament (Tibial Tuberosity Transposition)
  2. Deepening of the trochlea groove (Trochleoplasty)
  3. Tightening the soft tissues on one side of the patella (Retinacular imbrication)
  4. Releasing or loosening the soft tissues on the other side of the patella (Medial release)

1.  Moving the point of attachment of the patellar ligament (Tibial Tuberosity Transposition)

The attachment of the patella tendon to the tibia is moved sideways so that the patella now sits over the trochlea groove.



This is done by moving the bone to which the patella ligament attaches across the front of the tibia and securing it using pins and or wires.



2.  Deepening of the trochlea groove (Trochleoplasty)

The trochlea groove is often very shallow in patella luxation cases, which means the kneecap can more easily dislocate.  This can be deepened by removing bone from beneath the articular cartilage surface of the groove so it is deepened without losing cartilage.

3.  Tightening the soft tissues on one side of the patella (Retinacular imbrication)

4.  Releasing or loosening the soft tissues on the other side of the patella (Medial release)



Using these techniques most patella luxations can be realigned and because of this, the majority dogs regain normal function.

Fracture Repair

Road traffic accidents are the most common cause of bone fractures in veterinary practice. Fractures vary greatly in complexity from the relatively undisplaced simple “greenstick” fracture of a long bone in a young animal, to extremely complicated joint fractures in mature patients.

We carry a range of External Fixation, ASIF plates, Locking plates and other bespoke implants to cater for all fractures, from the simple to the complex.













Investigation of Lameness

The cause of lameness in some animals can be frustratingly difficult to pinpoint. Careful attention to a detailed history, observing the animal in relaxed surroundings, and observation of gait over different terrains (flat ground, gradients, steps etc) can all add vital detail. In addition, we will often request video clips of what the individual is doing in its own home, as fear and excitement can often mask subtle discomfort.

Thorough clinical examination is always essential, and sometimes is all that is required to make a diagnosis.

Very often history, observation and clinical examination will provide a very high index of suspicion of certain lameness problems, but further investigation is required.

Investigation of Joint Disease

Investigation of joint disease always requires extremely thorough clinical examination. Often this will provide enough information to be fairly sure of a diagnosis, or at least pin point which joint or joints are involved. High quality radiographs are usually the next stage of investigation. Here at Hall Place Veterinary Centre we have state of the art Digital X ray facilities allowing us to produce outstanding images.

X ray images can also be augmented using contrast techniques where special dye is put into a joint to outline the joint capsule and other structures near the joint.

Arthrocentesis is a technique where a needle is placed in a joint to obtain a sample of joint fluid for analysis. Examination of joint fluid can give information about different types of inflammation or infection within the joint.

We also have the ability to look directly inside joints using miniature cameras with fibre optic lenses only millimetres thick. This technique known as arthroscopy gives use direct visualisation of what is happening within a joint, without causing damage. We can even perform certain operative procedures within joints using this technique.

Arthroscopy

Investigation of joint disease always requires extremely thorough clincal examination. Often this will provide enough information to be fairly sure of a diagnosis. However a number of ancillary diagnostic aids will help pinpoint pathology.

High quality digital radiographs (Xrays) are essential in preliminary investigation, and can be augmented by contrast techniques.

We now have the ability to look directly inside joints using miniature cameras with fibre-optic lens only millimeters wide. This procedure, known as arthroscopy, can give us valuable information about what is happening in the joint without causing damage. We can even perform a number of operative procedures within the joint using this technique.

Medical Management of Lameness

Many joint diseases can be managed without surgical intervention. Treatment often involves careful restriction of exercise, and the use of anti-inflammatory and analgesic drugs.

We carry a large range of different anti-arthritic, anti-inflammatory and analgesic drugs.

The main class of drugs used in treatment of joint pain in humans and animals is the Non Steroidal Anti Inflammatory Drugs group, often know as “NSAIDS”. Examples in human use include aspirin and ibuprofen.

The most commonly used NSAIDS in veterinary practice are:

  • Carprofen
    (trade names include Rimadyl)
  • Meloxicam
    (trade names include Metacam/Loxicom)
  • Fibricoxhib
    (Trade name Previcox)

Less commonly used include:

  • Trocoxil
  • PLT
  • Onsior

Joint Supplements

Just as in human arthritis, a large number of “joint supplements” are available. The most commonly used of these contain Chondroitin and Glucosamine, and increasingly also Omega3 fatty acids. These molecules form some of the basic building blocks of cartilage and joint fluid. The theory is that providing the body with more than enough basic building blocks will ensure cartilage and joint fluid will always be maintained as good condition as possible.

Green lipped mussel extract has also been reported as beneficial in joint mobility and is available as a supplement or even already added to food.

In a similar manner to the use of anti-arthritic drugs in humans, some drugs work particularly well in one individual and not in another. Sometimes it is necessary to try different drugs or combinations of drugs and supplements to get the best results.

Joint Surgery

Many joint diseases can be managed medically, and we carry a large range of different anti-arthritic, anti-inflammatory and analgesic drugs. See medical management of lameness.

Some joint diseases or injuries require surgical intervention.

We offer a complete range of joint surgery from arthroscopic examination and treatment of shoulder and elbow cases, through arthrotomy and complex reconstruction of multi-ligament joint injuries or joint fractures.

A significant proportion of our work involves stifle (knee) lameness associated with cruciate ligament injury.

This is so important this is covered in a separate section. See Cruciate Surgery

Referring Vets

Referring a case

If you would like to refer a case please telephone 01628 622086.

Discussing a case

If you would like to discuss a case, either for free advice regarding a case you are managing, or with a view to referral please phone the above number.

Radiographic Reporting

Verbal reports on submitted radiographs are free of charge. As above this is often of value in deciding whether a case needs referral or not.
